Description
| type | Diameter of impeller | Rotating Speed of impeller (r/min) | max rate abrasive flow （kg/min） | Power of Motor （kw） |
|---|---|---|---|---|
| 360 | 250mm | 2940 | 240 | 15 |
| type | Linear Velocity | Number of Blades | Weight（kg） |
|---|---|---|---|
| 360 | 56m/s | 8 |
| Wear Parts | Method | Material | Life Time |
|---|---|---|---|
| Blades | Precision Casting | Cr18Mo0.5 | >=800h |
| Control Cage / Distributor | Precision Casting | Cr18Mo0.5 | >=800h |
| Protection Plate | Precision Casting | Cr18Mo0.5 | >=1500h |
| Side Plate | Precision Casting | Cr18Mo0.5 | >=1500h |
| Impeller | Machining | 40Cr | >=2500h |
